AK系列参数(2U机型):
|
特性/型号 |
AK200 |
AK300 |
AK400 |
AK500 |
AK600 |
AK700 |
|
输出功率8Ω(ST) |
2×250W |
2×350W |
2×450W |
2×500W |
2×600W |
2×700W |
|
输出功率4Ω(ST) |
2×400W |
2×500W |
2×600W |
2×800W |
2×900W |
2×1100W |
|
桥接输出功率8Ω(MON) |
|
|
1100W |
1300W |
1500W |
2000W |
|
频率响应 |
20Hz～20KHz±0.5db |
|||||
|
总谐波失真（THD%） |
＜0.03%/8Ω 1KHz |
|||||
|
信噪比 S/N |
＞95dB |
|||||
|
瞬态响应 |
35V/µs |
|||||
|
阻尼系数8Ω |
＞300 |
|||||
|
输入阻抗 |
20KΩ(Balanced)/10KΩ(Unbalanced) |
|||||
|
输入灵敏度 |
0.775V/1.0/1.4(mv/8Ω) |
|||||
|
体积Size(W*D*H) |
483×420×88mm (2U) |
|||||
AK系列参数(3U机型):
|
特性/型号 |
AK800 |
AK1200 |
AK1300 |
|
|
|
|
输出功率8Ω(ST) |
2×800W |
2×1200W |
2×1300W |
|
|
|
|
输出功率4Ω(ST) |
2×1400W |
2×1800W |
2×2000W |
|
|
|
|
桥接输出功率8Ω(MON) |
2400W |
3600W |
4000W |
|
|
|
|
频率响应 |
20Hz～20KHz±0.5db |
|||||
|
总谐波失真（THD%） |
＜0.03%/8Ω 1KHz |
|||||
|
信噪比 S/N |
＞95dB |
|||||
|
瞬态响应 |
35V/µs |
|||||
|
阻尼系数8Ω |
＞300 |
|||||
|
输入阻抗 |
20KΩ(Balanced)/10KΩ(Unbalanced) |
|||||
|
输入灵敏度 |
0.775V/1.0/1.4(mv/8Ω) |
|||||
|
体积Size(W*D*H) |
483×420×133mm (3U) |
|||||
